Colors/Grades:
- The natural color of Delrin AF Blend is dark brown.
Size and Availability:
Rod / Round:
- Thickness: 1/4”, 1/2”, 3/4” and 1”thick
- Sheet size: 24” x 48”
- Colors: Dark Brown
Sheet / Plate:
- Thickness: 1/4”, 1/2”, 3/4” and 1”thick
- Sheet size: 24” x 48”
- Colors: Dark Brown
|
Delrin® AF Blend is a unique thermoplastic material for use in moving parts in which low friction and long wear life are important. It is a
combination of PTFE fibers uniformly dispersed in Delrin® acetal resin. This combination offers better wear characteristics than unfilled Delrin®.
Delrin® AF Blend, supplied as a 2:1 blend of Delrin® AF100 and Delrin® 150 resins, has excellent sliding/friction properties. Bearings made of
Delrin® AF Blend can operate at higher speeds while exhibiting reduced wear. These bearings are also essentially free of slip-stick behavior
because the static and dynamic coefficient of friction is closer than with most plastics.
Delrin® AF Blend retains 90% of the strength that is inherent in unmodified Delrin acetal. Some properties are changed due to the addition of
the softer PTFE fiber. The natural color of Delrin® AF Blend is dark brown.
Features:
- Low moisture absorption
- High strength and stiffness
- Easy to machine
Applications:
- Bearings and bushings
- Electrical components
- Structural keels
- Gears and rollers
|
